For access, remove this FRU:
| Base cover removal and installation instructions |
|---|
Note: Loosen the screws 1 .
Applying labels to the base cover:
The new base cover FRU is shipped with a kit containing labels of several kinds. Apply those labels when you replace the base cover. For the labels that are not shipped with the new base cover, peel them from the old base cover, and adhere them to the new one.
The following illustration shows the location of each label.
The following labels need to be peeled off from the old base cover, and then adhered to the new base cover.
- S/N label
- Brazil WLAN label
- Brazil Bluetooth label
- Brazil 3G label
- SIRIM label or Postel label
- China WWAN/modem label
- Certificate of Authenticity (COA) label
- Genuine Microsoft label
- Israel WLAN label
- Israel Bluetooth label
- Israel 3G label
- Asset tag
- Swiss SIM ICCID label
- Non-encryption label
- Indonesia rating label
- Geo label for Japan and Korea
- Geo label for Mainland China and Taiwan Region
|
